7-4 1761-NET-ENIW Web Server Capabilities
The ENIW allows limited HTML formatting. For example, the string
‘Go to Allen-Bradley website’ would create a bold title.
Links may also be configured with the ENI/ENIW Configuration
Utility.
IMPORTANT
The ENIW does not validate the URL.
Table 7.2 Defining URL Links on the Home Page
Node 200
Defines
For User Link
Offset
(1)
(1) Use with SLC/MicroLogix 485CIF Write MSG instruction.
Element
(2)
(2) Use with Logix PLC-2 Unprotected Write MSG instruction.
3
0600
Title
1
4
01000
URL
5
01200
Title
2
6
01400
URL
7
01600
Title
3
8
02000
URL
9
02200
Title
4
10
02400
URL
11
02600
Title
5
12
03000
URL
13
03200
Title
6
14
03400
URL
15
03600
Title
7
16
04000
URL
17
04200
Title
8
18
04400
URL
19
04600
Title
9
20
05000
URL
21
05200
Title
10
22
05400
URL
TIP
Unused links cannot be removed from the list.
Rename them ‘reserved’ to indicate they are not
used.
