8–12

Reference

Publication 1395.5.37 – March, 1999

Parameter 457 – [A>CnltNet Out 7]
Parameter 357 – [B>CntlNet Out 7]

Use: ControlNet Output word #7
Parameter Type: Fast Sink
Program Terminal Units: None
Minimum Value: (Link Dependent)
Maximum Value: (Link Dependent)
Default Value: None

Description: This parameter is a fast sink that provides the seventh
word or group of data to the PLC controller input image table.
The value can be provided by the CNA board directly or by other
Drive functions through a configuration link.

Parameter 550 – [A>ICN Fault Select]
Parameter 500 – [B>ICN Fault Select]

Use: Selection for Soft Fault configuration
Parameter Type: Setup
Program Terminal Units: None
Minimum Value: 0
Maximum Value: 255 (FFh)
Default Value: 175 (AFh)

Description: Value of 1 in any bit position configures the fault
condition to be a Soft Fault.

Parameter 551 – [A>ICN Warn Select]
Parameter 501 – [B>ICN Warn Select]

Use: Selection of Warning configuration
Parameter Type: Setup
Program Terminal Units: None
Minimum Value: 0
Maximum Value: 255 (FFh)
Default Value: 47 (2Fh)

Description: Value of 1 in any bit position configures the fault to be a
Warning condition.

551/501

Warn Sel

Treated and

Reported as:

552/502

ICN Fault Status

550 / 500
Fault Sel

0

0

1

1

Ignore

Warning

Soft Fault

Soft Fault

0

1

0

1

553/503

ICN Warn Status

0

0

1

1

0

1

0

1
