8–2

Reference

Publication 1395.5.37 – March, 1999

Source Parameter A parameter which contains real time information

that is available for use by other devices. These
devices can include PLC controllers, operator
interface devices, program terminals, etc.

Sink Parameters

Sink parameters accept data from other parameters
which is then used by the Drive to perform the
desired functions. An example of a sink is the
external velocity reference parameter which
accepts a speed reference from a device such as a
PLC.

Detailed Parameter Listing

Certain parameter numbers and definitions in the CNA board are
dependent on the specific channel assignments as detailed in Table 8.A.

Table 8.A. CNA Board Parameter Channel Assignments

300 – 307

350 – 357

500 – 504

Parameter

Numbers

Port B

Useage

ControlNet Out

ControlNet In

ICN Fault/Warning – CNet Dip Switches

400 – 407

450 – 457

550 – 554

Parameter

Numbers

Port A

Parameter Name Structure

The example below shows a typical parameter name.

Parameter 300:

Cntl Net Out – 0

Parameter description Designator

Function

Parameter Table Structure

Table 8.B contains an abbreviated listing of the CNA board parameters.
The parameters in the Adapter can be categorized into the following
general groups by parameter number:

S #300 – #307 Port B Source Parameters

S #350 – #357 Port B Sink Parameters

S #400 – #407 Port A Source Parameters

S #450 – #457 Port A Sink Parameters

S #500 – #504 Port B Common Parameters

S #550 – #554 Port A Common Parameters
