ArmorStart
®
EtherNet/IP
™
Communications & Control Programming Manual Appendix A
This section explains the various bits in the Trip Status word and the faults they
represent.
Bulletin 280E Trip Status
The table below shows the default input (produced) assembly for Bulletin 280E.
Bytes 10 and 11 make up the word called Parameter 14, Prod Assy Word 1. The
Prod Assy Word
points to a parameter and returns the value of that parameter. In
this case, Parameter 14 Prod Assy Word 1 points to parameter 4, which is the
Trip Status
parameter. Cross reference the parameter 14, Prod Assy Word 1 value
to the Trip Status parameter definition to understand what faults are being
reported.
Instance 150 "Starter Stat" – Default Status Assembly for Bulletin 280E/281E Starters
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
Reserved (Referenced in the Add-On-Profile as “Fault”)
1
Reserved (Referenced in the Add-On-Profile as “Fault”)
2
Reserved (Referenced in the Add-On-Profile as “Fault”)
3
Reserved (Referenced in the Add-On-Profile as “Fault”)
4
—
—
—
Ready
Running Rev
Running Fwd
Warning
Tripped
5
—
—
140M On
HOA
Input 4
Input 3
Input 2
Input 1
6
Net Out 7
Net Out 6
Net Out 5
Net Out 4
Net Out 3
Net Out 2
Net Out 1
Net Out 0
7
Logic Enable
Net Out 14
Net Out 13
Net Out 12
Net Out 11
Net Out 10
Net Out 9
Net Out 8
8
Value of the parameter pointed to by "Parameter 13 Prod Assy Word 0" (low byte)
9
Value of the parameter pointed to by "Parameter 13 Prod Assy Word 0" (high byte)
10
Value of the parameter pointed to by "Parameter 14 Prod Assy Word 1" (low byte)
11
Value of the parameter pointed to by "Parameter 14 Prod Assy Word 1" (high byte)
12
Value of the parameter pointed to by "Parameter 15 Prod Assy Word 2" (low byte)
13
Value of the parameter pointed to by "Parameter 15 Prod Assy Word 2" (high byte)
14
Value of the parameter pointed to by "Parameter 16 Prod Assy Word 3" (low byte)
15
Value of the parameter pointed to by "Parameter 16 Prod Assy Word 3" (high byte)
Trip Status
This parameter provides trip
identification.
Parameter Number
4
Access Rule
GET
Data Type
WORD
Group
Basic Status
Units
—
Minimum Value
0
Maximum Value
16383
Default Value
0
Point to
parameter 4,
Trip Status
