6. Advanced
An alternative to a full screen White/black pattern is the standard gray scale pattern, the white bar will be used
for white balance and the black bar for black balance.
Image 6-55
It is not necessary to adjust the black balance. Its value is automatically set to an optimal value.
Performing White input balance
1. Select a black pattern (or gray scale as alternative)
2. Press MENU to activate the Toolbar
3. Press → to select the Image item
4. Press ↓ to Pull down the Image menu
5. Use ↑ or ↓ to select Input balance
6. Press → to pull down the menu
7. Use ↓ or ↑ to select White balance
Image 6-56
8. Adjust the red white level (gain) on a minimal value
Image 6-57
