6. Advanced
Important ! In the projectors iD R600 and iD Pro R600 (R9010340 and R9010350) the measuring is done with
white peaking = 0.
In the projectors iD R600+ and iD Pro R600+(R9010341 and R9010351) however, the white peaking must be 10
during the measurement.
The dialogbox shown here are as displayed in the iD R600 and iD Pro R600 (with the field White ).The dialogbox
displayed in the iD R600+ and iD Pro R600+ contain the field White+ instead of White.
The Dynacolor™ Interface
Following parameters are available in the Dyancolor™ Interface:
Measured Values These are the colors the projector displays when no color changes are made
Red x, y Coördinates for the Red point
Green x, y Coördinates for the Green point
Blue x, y Coördinates for the Blue point
White x, y Coördinates for the White point
Red L Red Light output
Green L Green Light output
Blue L Blue Light output
White L White Light Output
Desired Values These are the colors you want the projector to display when the status is enabled
Red x, y Coördinates for the Red point
Green x, y Coördinates for the Green point
Blue x, y Coördinates for the Blue point
Cyan x, y Coördinates for the Cyan point
Yellow x, y Coördinates for the Yellow point
Magenta x, y Coördinates for the Magenta point
White x, y Coördinates for the White point
Red g Red Light Gain
Green g Green Light Gain
Blue g Blue Light Gain
Cyan g Cyan Light Gain
Yellow g Yellow Light Gain
Magenta g Magenta Light Gain
White g White Light Gain
Status Enables or disables Dynacolor™
Factory Preset Sets the measured parameters back to the factory preset for the current set
Basic Dynacolor™ Adjustment
We assume we have a basic setup with 2 projectors, the Dynacolor™ adjustment is done by using only the Dynacolor™ menu:
1. Enable Dynacolor™ on both projectors.
2. Assume the first projector has the following measured values.
66 R59770134 ID LR-6 27/05/2011
