4 positioning the projector, Positioning the projector – Barco ID LR-6 R9010342 User Manual
Page 17
3. Installation
1
2
3
4
Image 3-6
The configuration should also be communicated to the projector. This is done in the Installation menu through
the Projector Configuration parameter. (See Setup section)
3.4
Positioning the projector
On-Axis projection
Projection where the projector is positioned so as to have the centre of the lens coinciding with the centre of the screen.
Positioning the projector
The position of the projector with reference to the screen may also be different depending on the installation. Basically the projector
can be positioned in an On-Axis or Off-Axis configuration. Several parameters can be calculated determining the position in any
installation.
R59770134 ID LR-6 27/05/2011
13
