9 blanking, Blanking, Advanced – Barco ID LR-6 R9010342 User Manual
Page 104
6. Advanced
A dialog box is displayed.
Image 6-111
6. Use the arrow keys to select the desired item and press ENTER to activate or disactivate the item.
How to perform AutoImage ?
1. Press AutoImage on the RCU
A textbox showing a progress bar is displayed.
During the AUTOIMAGE measuring process the data source disappears temporarily (logo is displayed if back-
ground is set to logo )
6.9.9
Blanking
What can be done ?
The image can be blanked in several ways :
•
Top blanking
•
Bottom blanking
•
Left blanking
•
Right blanking
Image 6-112
100
R59770134 ID LR-6 27/05/2011
