3. Installation
3.5.2.1 Input section
Input Layers
The input section is divided in layers, each of them regrouping several inputs, this architecture allows the input section to be upgraded
at any time with an optional analog or digital layer.
1.
Layer 1: analog layer containing analog data and video inputs
2. Layer 2: a hybrid layer containing 2 digital and 1 analog input
3. Layer 3 : is an optional layer, it may be an Audio & Video analog layer or a SDI digital layer.
The optional layer is not available for the Pro version
3.5.2.2 Input facilities
The optional features are also explained in this manual, they are always mentioned with “(optional)”
The SDI and Audio option is not possible on the Pro version !
overview
• 5–cable input
• composite video
• component video (PR/Y/PB)
• S-Video
• Digital Visual Input (DVI)
• Computer
• Serial Digital Input (Optional)
• Audio input/output (Optional)
R59770134 ID LR-6 27/05/2011 17
