Chapter 3
Configuring the Adapter
This chapter provides instructions and information for setting the
parameters to configure the adapter.
For a list of parameters, refer to Appendix B , Adapter Parameters . For
definitions of terms in this chapter, refer to the Glossary .
Configuration Tools The adapter stores parameters and other information in its own non-volatile
memory. You must, therefore, access the adapter to view and edit its
parameters. The following tools can be used to access the adapter
parameters:
Topic Page
Configuration Tools 3-1
Using the PowerFlex 7-Class HIM 3-2
Setting the Node Address 3-3
Setting the Data Rate 3-3
Setting the I/O Configuration 3-4
Selecting COS, Cyclic or RTR I/O Data Exchange 3-5
Setting a Fault Action 3-7
Resetting the Adapter 3-9
Viewing the Adapter Status Using Parameters 3-10
Flash Updating the Adapter 3-10
Tool Refer to…
PowerFlex HIM page 3-2
DriveExplorer Software
(version 4.01 or higher) http://www.ab.com/drives/driveexplorer, or
DriveExplorer online help (installed with the software)
DriveExecutive Software
(version 3.01 or higher) http://www.ab.com/drives/drivetools, or
DriveExecutive online help (installed with the software)
TIP: Service Data Objects can also be used to configure an adapter and
drive. Refer to
Chapter 6 , Using Service Data Objects .
