Description Item
Assign to Interlock: Select a interlock chain (1–8) for the HSM
interlocks.
Typically, the interlock chain assignment that you make in the .hwi
file should match the interlock chain that you assign to the station
when you load it in Station Manager.
Low Flow Interlock: True or False, True=controller responds to a
low-flow interlock signal on J3.
FlexTest IIm Chassis Settings
The following hardware settings are only available on the Chassis tab that appears for FlexTest
IIm controllers.
Description Item
There can be up to two Model 497.01 Analog Chassis. This block
defines a chassis number. See the ADDA definition for more
information. 497.01 Analog Chassis
chassis icon
Chassis: Not applicable.
Host Port: Not applicable.
The hydraulic station definition describes the Model 497.05 Hydraulic
Control Panel chassis. At least one HSM must be defined. The 497.05 Hydraulic Control
Panel chassis icon
FlexTest IIm software and the Model 497.05 Chassis supports up to
4 stations.
Chassis: Not applicable.
Host Port: Not applicable.
Name: Describes this resource as it will appear in Station Builder
resource lists when opened against an .hwi file. Hydraulic Interface icons
Changing this name may invalidate existing station configurations.
Connector: The connector number represents a rear panel connector
on the chassis.
