Description Item
Zero—Clamps the servovalve to zero—if valve balance is used, it will
clamp to this value.
Positive—Clamps the servovalve to positive 50% spool opening on
a 2-stage valve driver, 50% outer-loop command on the 3-stage valve
driver.
Negative—Clamps the servovalve to negative 50% spool opening on
a 2-stage valve driver, 50% outer-loop command on a 3-stage valve
driver.
Range: Defines the output (in mA) of the valve driver. The settings
are 25 or 50. 2SVD icon
Mode: Identifies single or multiple valve driver support. The settings
are Single or Dual.
Dual valve driver support requires a special manifold.
Model 493.2x DUC Card Settings
Settings for the Model 493.21 DUC Card, 493.21B DUC Card, and 493.25 DUC card.
Description Item
The conditioner definitions describe the characteristics of the Digital
Universal Conditioner (DUC) mezzanine card. 493.2x DUC mezzanine
card icon
Name: Describes this resource as it will appear in Station Builder
resource lists when opened against an .hwi file. Analog Input icon
Changing this name may invalidate existing station configurations.
Connector: Describes the connector that joins the resource to the
chassis. This will likely move up to the daughter level.
Filter: Settings include: 0 (no filter), 50 (Hz), 100 (Hz), 300 (Hz), 500
(Hz), or 1000 (Hz).
Mode: Specifies the type of conditioning (AC or DC) the DUC will
perform. DUC icon
DUC Icon Right-click Options
Right-click the 493.21B or 493.25 DUC icon to select from the
following options:
• Add Acceleration Compensation
• Add DIO Load Washer
• Add Serial Load Washer
