Mezzanine Card Compatibility
The following table lists the different mezzanine cards and the type of carrier board where they
can be used.
493.50
ADDA II
Board 498.65
ADDA
Board 494.40
I/O
Carrier 493.40
I/O
Carrier Mezzanine Card
X 493.14 2SVD #
X 493.15 3SVD #
X 493.21 DUC, 493.21B DUC, 493.25 DUC
X 493.45 6-A/D
X 493.46 6-output D/A
X 493.47 Encoder Card
X 493.48 Accelerometer Input
X 493.55 8-A/D (8-Channel), 493.57 8-A/D (8-Channel)
X 493.56 8-D/A (8-Channel)
X 493.59-1 U2 Absolute, 493.59-3 U2 Incremental, 493.59-5
U2 Temposonics III
X 494.16 VD/DUC
X 494.25 Single DUC, 494.26 Dual DUC
X 494.45 8-Input A/D
X 494.46 8-Output D/A
X 494.47 Dual UART/Encoder
X 493.65A-10 8-A/D (8-Channel)
X 493.65A-11 8-D/A (8-Channel)
X 493.65A-12 Encoder, 493.65A-15
Temposonics,493.65A-16 Temposonics III, 493.65A-17
Heidenhain 417,493.65A-18 Heidenhain 425, 493.65A-61
U2 Incremental,493.65A-62 U2 Tempo III, 493.65A-66 U2
Absolute
46 MTS Series 793 Utility Software
HWI Hardware Settings
