Transition Board Settings
Transition boards are used in FlexTest GT, TestStar IIm, Aero ST, and FlexTest 60/100/200
controllers.
Model 493.72 Digital I/O Transition Board Settings
Description Item
The DI/O Transition Board definition describes the Model 493.72
Digital I/O Transition Panel digital input and outputs. The information
shown defines 16 digital inputs and 16 digital outputs. 493.72 DI/O transition
board icon
Transition Slot: Specifies the transition slot where this board is
installed.
Name: Describes this resource as it will appear in Station Builder
resource lists when opened against an .hwi file. Digital Input/Digital Output
icon
Changing this name may invalidate existing station configurations.
Connector: Describes the connector that joins the resource to the
chassis. This will likely move up to the daughter level.
Model 493.73 HPU Transition Board Settings
Description Item
Transition Slot: Specifies the transition slot where this board is
installed. 493.73 HPU transition
board icon
Name: Describes the hardware resource as it will appear in Station
Builder resource lists. Hydraulic Interface icon
Changing this name may invalidate existing station configurations.
Connector: J25. (Should this be read only?)
HPU with HSM: True: Indicates the system’s HPU supplies additional
HSMs. False: used for HPU only systems (makes HPU selection
available in Station Builder).
Type:
Off-high–only two HPU control buttons (Off/High) will appear on the
Station Manager Station Controls panel.
