Model 498.65 ADDA Board Settings
This card is compatible with FlexTest IIm controllers.
Description Item
When the optional Model 498.65 ADDA board is being used, the .hwi
file describes this board and the A/D, D/A, and various mezzanine
cards that are installed on it, as follows: 498.65 ADDA circuit board
icon
• Model 493.65A-10 8-A/D (8-Channel)
• Model 493.65A-11 8-D/A (8-Channel)
• Model 493.65A-12 Encoder
• Model 493.65A-15 Temposonics
• Model 493.65A-16 Temposonics III
• Model 493.65A-17 Heidenhain 417
• Model 493.65A-18 Heidenhain 425
• Model 493.65A-61 U2 Incremental
• Model 493.65A-62 U2 Temposonics III
• Model 493.65A-66 U2 Absolute
Each mezzanine card can be assigned to one of the four ADDA
board connectors. Each mezzanine card definition is followed by
four or eight signal definitions.
Address: Describes the proximity of the circuit board within the
chassis. This value is generated during initialization, and should be
changed only if the value read in from an existing .hwi file is in error. Properties tab
Slot: Specifies which slot the circuit board occupies in the chassis.
Mezzanine n Mezzanines tab
Model 498.70 Digital I/O Board Settings
This card is compatible with FlexTest IIm controllers.
Description Item
Address: Describes the proximity of the circuit board within the
chassis. This value is generated during initialization, and should be
changed only if the value read in from an existing .hwi file is in error. 498.70 DI/O circuit board
icon
Slot: Specifies which slot the circuit board occupies in the chassis.
Name: Describes this resource as it will appear in Station Builder
resource lists when opened against an .hwi file. Digital Input/Output icon
44 MTS Series 793 Utility Software
HWI Hardware Settings
