Description Item
Changing this name may invalidate existing station configurations.
Connector: Identifies the I/O Carrier rear panel connector that is
available for MUD board output. This will likely move up to the
daughter level.
Mode: Specifies what type of device is to be connected. Options are
Incremental, Temposonics 24 Bit, Temposonics 25 Bit, and Teledyne
(absolute encoder, hardware supports 17-bit resolution). Encoder icon
Model 493.48 Accelerometer Input Card Settings
Description Item
On systems affected by acceleration induced errors, an optional
acceleration conditioner board can be linked to a conditioner (DUCB
only) to perform acceleration compensation. 493.48 Accel. Input
mezzanine card icon
The acceleration conditioner definition specifies a list of auxiliary
inputs that the DUC conditioners can use on the acceleration
mezzanine card. (Each DUC mezzanine card definition is enhanced
to allow an auxiliary input to be defined.)
Name: Describes this resource as it will appear in Station Builder
resource lists when opened against an .hwi file. Accel. Input icons
Changing this name may invalidate existing station configurations.
Connector: Not applicable.
Model 493.50 ADDA II Mezzanine Cards
The mezzanine cards listed in this section can be used in the Model 493.50 ADDA II board. The
Model 493.50 board is compatible with FlexTest IIm, FlexTest GT, Aero ST, and TestStar IIm
controllers.
Model 493.55/493.57 8-Channel A/D Card Settings
Description Item
The Model 493.55 8-A/D mezzanine card, available for installation
on ADDA II boards, provides 8 channels of A/D with digital filtering. 493.55 and 493.57 8-A/D
mezzanine card icon
Filter settings can be applied to controller feedback, scope, meter,
