Description Item
Address: Describes the proximity of the mezzanine card within the
circuit board. This value is generated during initialization, and should Properties tab
be changed only if the value read in from an existing .hwi file is in
error.
Filter: Off/On.
Analog Output n Channels tab
Specifies an externally conditioned signal in the range of +/-10V. High Level
Excludes inputs to the selected channel. No Channel
Chassis: Not applicable. 497.15 3-Stage/497.26
Dual 2-Stage Valve Driver
icon
Slot: Specifies which slot the circuit board occupies in the chassis.
Channel: Not applicable.
Filter: Not applicable.
Connector: Not applicable.
Model 498.65A-12 Encoder Card Settings
Description Item
The analog input definition describes the encoder mezzanine card. 498.65A-12 Encoder/ -15
Temposonics/ -16
The connector specification identifies the rear panel connector that
is available for analog inputs.
Temposonics III/ -17
Heidenhain 417/ -18
Address: Describes the proximity of the mezzanine card within the
circuit board. This value is generated during initialization, and should Heidenhain 425/ -61 U2
Incremental/ -66 U2
be changed only if the value read in from an existing .hwi file is in
error. Absolute mezzanine card
icon
Filter: Off/On.
Name: Describes this resource as it will appear in Station Builder
resource lists when opened against an .hwi file. Analog Input icon
Changing this name may invalidate existing station configurations.
Address: Not applicable.
Connector: Describes the connector that joins the resource to the
chassis. This will likely move up to the daughter level.
72 MTS Series 793 Utility Software
HWI Hardware Settings
