Unexpected actuator movement can result in injury to personnel or damage to the
equipment.
Enable the gate interlock option for systems that include a Slow (low-flow) mode for
specimen installation.
Model 494.74 HSM Transition Board
Description Item
The hydraulic control definition assigns the Hydraulic Power Unit
(HPU) transition board and each Hydraulic Service Manifold (HSM) 494.74 HSM transition
board icon
transition board to their appropriate rear panel connectors. Each of
the two HSM transition boards allowed in your system can support
up to two HSM stations.
Transition Slot: Not applicable.
Changing this name may invalidate existing station configurations. Hydraulic Interface icon
Name: Describes this resource as it will appear in Station Builder
resource lists when opened against an .hwi file.
Connector: J28A or J28B.
Type: Solenoid or On/Off Solenoid.
On/Off Solenoid: only two HSM control buttons (Off/On) will appear
on the Station Manager Station Controls panel.
Solenoid: three HSM control buttons will appear (Off/Low/High).
Connect to HPU:
True: Indicates the HSM requires the HPU to be started (either
manually or as “first on”) prior to be started.
False: Indicates the HSM can be activated without an HPU activation.
Changing this name may invalidate existing station configurations. Hydraulic Interface icon
Name: Describes this resource as it will appear in Station Builder
resource lists when opened against an .hwi file.
Connector: J28A or J28B.
Interlock: Select a interlock chain (1–8) for the HSM interlocks.
Typically, the interlock chain assignment that you make in the .hwi
file should match the interlock chain that you assign to the station
when you load it in Station Manager.
Type: Solenoid or On/Off Solenoid.
Connector: J3. Interlock Interface icon
