a) Click the Serial LoadWasher icon.
b) From the Serial Port drop-down list, select the serial port where the loadwasher is connected.
c) Verify the scale settings are correct for the loadwasher that you are using.
d) If you want to assign custom names to each range, use the Hwi FIle Editor application to
change the range names to match the range names that you will use in the Station Manager
application.
Note:
The range names that appear in the Serial LoadWasher Properties tab must match
the range names assigned in the Sensor tab in the Station Manager application.
Model 493.45 Six-Channel A/D Card Settings
Description Item
Describes the six-channel analog-to-digital converter
mezzanine card. 493.45 6-Input A/D mezzanine card
icon
Analog Input n Channels tab
Specifies an externally conditioned signal in the range of
+/-10V. High Level
Excludes inputs to the selected channel. No Channel
Name: Describes this resource as it will appear in Station
Builder resource lists when opened against an .hwi file. Analog Input icon
Changing this name may invalidate existing station
configurations.
Connector: Describes the connector that joins the resource
to the chassis. This will likely move up to the daughter level.
Model 493.46 Six-Output D/A Card Settings
Description Item
Describes the six-channel digital-to-analog converter mezzanine
card. 493.46 6-Output D/A
mezzanine card icon
Properties tab
Analog Output n Channels tab
Specifies an externally conditioned signal in the range of +/-10V. High Level
50 MTS Series 793 Utility Software
HWI Hardware Settings
