and limit detector signals. Each D/A mezzanine card definition is
followed by eight signal definitions.
Filter: On/Off. Properties tab
The 493.57 A/D Card includes an elliptical filter with the following
settings (available through the Analog Input icon): off, 500, 1000,
1500, 2000 Hz.
Analog Input n Channels tab
Specifies an externally conditioned signal in the range of +/-10V. High Level
Excludes inputs to the selected channel. No Channel
Chassis: Not applicable. 497.13 AC/497.14
AC/497.22 Dual DC
Conditioner icon
Slot: Specifies which slot the circuit board occupies in the chassis.
Channel: Not applicable.
Filter: On/Off.
Connector: Not applicable.
Model 493.56 8-Channel D/A Card Settings
Description Item
The analog output definition describes the D/A Analog Output
mezzanine card. 493.56 8-D/A mezzanine
card icon
The connector specification identifies the rear panel connector that
is available for analog outputs.
Filter: On/Off. Properties tab
Analog Output n Channels tab
Specifies an externally conditioned signal in the range of +/-10V. High Level
Excludes inputs to the selected channel. No Channel
Chassis: Not applicable. 497.15 3-Stage/497.26
Dual 2-Stage Valve Driver
icon
Slot: Specifies which slot the circuit board occupies in the chassis.
Channel: Not applicable.
Filter: Not applicable.
Connector: Not applicable.
