Homing
3−46
l
EDSVS9332P−EXT DE 2.0
3.4.8
Homing
Determination of the mechanical reference point for measuring systems.
After homing, the drive is in a defined position.
Functions
l
Homing (
¶ 3−46)
l
Homing end (
¶ 3−47)
l
Homing status (
l
Homing modes (
¶ 3−49)ff.
l
Second homing speed (
l
Set homing value(
¶ 3−57)
3.4.8.1
Homing
Purpose
Definition of the reference point in the absolute or relative positioning mode.
Function
l
Selection of a sequence suitable for homing (
l
Setting of the homing speed under C1242
– Setting of a second homing speed under C1241 (if necessary) (
¶ 3−56)
l
Setting of the homing acceleration under C1251
l
Definition of the final homing point under C1209.
l
Execution of homing in
– Manual operation via "manual referencing" (
– Program operation (GDC dialog "Programming" under PS mode" or selection under
C1311/x = 3, program set mode)
Homing procedure
l
The homing status POS−REF−OK is reset (see (
¶ 3−48)) and the current reference offset
initialised using the value entered under C1225.
l
Homing is started and carried out according to the mode selected under C1213.
l
If the reference point is found, the home position (C1227) is set and the reference offset
(C1225) is added. The position data now refer to the real zero point (see Fig. 3−12).
l
The homing status POS−REF−OK is set.
