Function library
Positioning control
3.4.13
Program sets (PS)
3−77
l
EDSVS9332P−EXT DE 2.0
3.4.13.1
PS mode
Purpose
l
Selection of which positioning or special function is to be carried out in the PS.
Function
l
GDC input: Programming" dialog
l
Factory setting: No positioning or special function
l
Input under PS mode (C1311):
Value
Program functions
0
No positioning or special function
1
Absolute PS
2
Relative PS
3
Homing
4
Set homing value
5
Set position value to target position (C1312)
6
Absolute PS; TP positioning with E01
7
Absolute PS, TP positioning with E02
8
Absolute PS, TP positioning with E03
9
Absolute PS, TP positioning with E04
11
Relative PS, TP positioning with E01
12
Absolute PS, TP positioning with E02
13
Relative PS, TP positioning with E03
14
Relative PS, TP positioning with E04
16
Acceptance of home position (C1227)
30
Stand−by operation, cancel with STDBY−STP
31
Stand−by operation, cancel with TP E01 and traversing of the residual distance
32
Stand−by operation, cancel with TP E02 and traversing of the residual distance
33
Stand−by operation, cancel with TP E03 and traversing of the residual distance
34
Stand−by operation, cancel with TP E04 and traversing of the residual distance
