Function library
Function blocks
3.5.67
Variable table − target position/position values (VTPOS)
3−278
l
EDSVS9332P−EXT DE 2.0
Signal
Source
Note
Name
Type
DIS
DIS format
CFG
List
VTPOS−IN1
ph
C1351/1
dec [inc]
C1350/1
3
−
VTPOS−IN2
ph
C1351/2
dec [inc]
C1350/2
3
−
VTPOS−IN3
ph
C1351/3
dec [inc]
C1350/3
3
−
VTPOS−IN4
ph
C1351/4
dec [inc]
C1350/4
3
−
VTPOS−IN5
ph
C1351/5
dec [inc]
C1350/5
3
−
VTPOS−IN6
ph
C1351/6
dec [inc]
C1350/6
3
−
VTPOS−IN7
ph
C1351/7
dec [inc]
C1350/7
3
−
VTPOS−IN8
ph
C1351/8
dec [inc]
C1350/8
3
−
VTPOS−IN9
ph
C1351/8
dec [inc]
C1350/9
3
−
VTPOS−IN10
ph
C1351/10
dec [inc]
C1350/10
3
−
VTPOS−OUT1
ph
−
−
−
−
−
...
...
VTPOS−OUT104
ph
−
−
−
−
−
Function
A total of 104 table positions are available.
l
Enter fixed target position values via C1301/x.
– 60 table positions (VTPOS−No1 ... VTPOS−No60) are available.
– Subcodes (C1301/1 ... C1301/60) define the table position number.
l
Enter variable target position values via VTPOS−INx.
– 10 table positions (VTVEL−No61 ... VTVEL−No70) are available.
– Signal input via function blocks.
– The target position value must be transmitted to the table positions before the
corresponding program set starts and accesses these values.
l
Enter target position values of FB TEACH1.
– 30 table positions (VTPOS−No71 ... VTPOS−No100) are available.
l
Enter target position values via touch probe.
– 4 table positions (VTPOS−No101 ... VTPOS−No104) are available.
l
C1380 displays the target position values (in units) on the table positions.
– Select table position (C1380/1 ... C1380/104) with subcode.
l
C1381 displays the target position values (in inc) on the table positions.
– Select table position (C1381/1 ... C1381/104) with subcode.
l
The conversion from target position [units] to target position [inc] is performed according to
the formula:
Target position [inc]
+ Target position [units] @
65536 [inc
ńr] @ gear nominator
Feed const. [units
ńr] @ gear denominator
Tip!
Entries into the processing table are only required if FB inputs are used.
