Function library
Function blocks
3.5.30 Digital frequency processing (DFSET)
3−178
l
EDSVS9332P−EXT DE 2.0
Function
l Setpoint conditioning with stretch and gearbox factor
l Processing of correction values
l Synchronising to zero track or touch probe (for resolver feedback touch probe only)
3.5.30.1 Setpoint conditioning with stretch and gearbox factor
Stretch factor
Defines the ratio between the drive and the setpoint.
l The stretch factor evaluates the setpoint at DFSET−IN. DFSET−POUT outputs the result.
l The stretch factor results from numerator and denominator.
– Numerator is variable from analog signal source or fixed value by the code.
– Input of the denominator under C0533.
l Relationship:
DFSET–POUT + DFSET–IN @ DFSET–VP–DIV
C0533
Gearbox factor
Defines the gearbox ratio of the drive. Enter the ratio of the drive.
l The gearbox factor evaluates the setpoint at DFSET−IN multiplied by the stretch factor.
DFSET−NOUT outputs the result.
l The gearbox factor results from the numerator and denominator.
– Numerator is variable from analog signal source or fixed value by the code.
– Input of the denominator under C0033.
l Relationship:
DFSET–NOUT + Reckfaktor @ DFSET–RAT–DIV
C0033
DFSET–NOUT + DFSET–IN @ DFSET–VP–DIV
C0533
@ DFSET–RAT–DIV
C0033
Tip!
With C0530 the gearbox factor and the DFSET−N−TRIM values can be deactivated as a basis for the
setpoint angle. In the case of C0530 = 1, only the stretch factor is used for calculating the setpoint
angle.
