Configuration
Configuration with Global Drive Control
2−3
l
EDSVS9332P−EXT DE 2.0
2.1 Configuration with Global Drive Control
With Global Drive Control (GDC), a program for the PC, Lenze offers an easy−to−understand,
clearly−laid−out and convenient tool for configuring your application−specific drive task.
Function block library
GDC provides a clear overview of the function blocks (FB) available in a library. GDC also lists the
complete assignment of a function block.
Signal configuration
Signals can be configured in a single dialog box. This is a convenient way
l to display every FB as a block diagram.
l to see the assignment of all signal inputs at a glance.
l to enter the FB in the processing table.
l to print your signal configuration.
Terminal assignment
Freely assignable terminals can be configured using two dialog boxes:
l Dialog box − to link digital inputs and outputs.
l Dialog box − to link analog inputs and outputs.
