Parameter data transfer
Special features for parameter setting of the drive controller
9300 Servo PLC / Drive PLC / ECS
10
l
82 EDSMF2178IB EN 3.0
Example
By writing the value "2" into the AIF control byte all codes C23XX are re−read when the MSB
changes its status.
For some codes it is necessary to carry out a CAN reinitialisation so that new values and the
functions derived from them will become effective.
C2121:
AIF status byte
Code Subcode Index Possible settings Data type
Lenze Selection
C2121 − 22454 =
0x57B6 0 0 [1] 255 U8
The AIF status byte provides the 9300 Servo PLC, Drive PLC and ECS with information of the
communication module. With this information, the 9300 Servo PLC, Drive PLC and ECS can
monitor the status of the communication module . Depending on the communication
module states, it is possible for you to take corresponding countermeasures.
AIF status byte Description
Bit 0 CE11 error, CAN−IN1 monitoring time exceeded
Bit 1 CE12 error, CAN−IN2 monitoring time exceeded
Bit 2 CE13 error, CAN−IN3 monitoring time exceeded
Bit 3 CE14−error, communication module in BUS−OFF status
Bit 4 Operational status
Bit 5 Pre−operational state
Bit 6 Warning status
Bit 7 Internally assigned
