Codes
Communication−relevant Lenze codes
14
l
124 EDSMF2178IB EN 3.0
C1851/C2351:
Baud rate
Code Subcode Index Possible settings Data type
Lenze Selection
C1851 − 22724 =
0x58C4 0 0 ... 4 0: 500 kbps
1: 250 kbps
2: 125 kbps
3: 50 kbps
4: 1000 kbit/s FIX32
C2351 − 22224 =
0x56D0
This code serves to set the baud rate of the communication module.
ƒ The baud rate must be the same for all CAN nodes.
ƒ The baud rates 10 kbps and 20 kbps can only be selected via DIP switch(
¶ 33).
ƒ Setting the code (e.g. with GDC via CAN) has a direct effect on the standard device
code C0125.
)
Note!
ƒ The baud rate must be the same for all CAN nodes.
ƒ The baud rates 10 kbps and 20 kbps can only be selected via DIP
switch(
¶ 33).
ƒ All DIP switches 1 ... 7 = OFF (Lenze setting):
– When the device is switched on, the settings under code C1850/C2350
(node address) and C1851/C2351 (baud rate) are active.
– Code C1851/C2351 is an image of code C0125 of the basic drive. Setting
C1851/C2351 has a direct effect on C0125.
