Parameter data transfer
Special features for parameter setting of the drive controller
8200 vector controller
10
l
81 EDSMF2178IB EN 3.0
10.6 Special features for parameter setting of the drive controller
10.6.1 8200 vector controller
The digital and analog input and output signals are freely configurable (see System
Manual 8200 vector; code C0410, C0412, C0417 and C0421).
10.6.2 9300 Servo PLC / Drive PLC / ECS
AIF control byte (C2120)/AIF status byte (C2121)
The controller and the EMF2178IB communication module are able to exchange control
and status information. For this purpose, a control byte and a status byte are made
available in the AIF protocol.
C2120:
AIF control byte
Code Subcode Index Possible settings Data type
Lenze Selection
C2120 − 22455 =
0x57B7 0 See table below FIX32
Possible settings
Selection Description
0 No command
1 Update codes 23XX and CAN reinitialisation º reset node
2 Update codes C23XX
10 Reread C2356/1...4
11 Reread C2357
12 Reread C2375
13 Reread C2376 ... C2378
14 Reread C2382
16 1) Update C7999 and C7998 including CAN reinitialisation
17 1) Update C7999, mapping table of profile indices
18 1) Update C7998, error list of emergency messages
32 1) Reset error source, activate emergency messages
33 ... 62 1) Error source 1 ... 30, activate emergency messages
1) Value range is only valid for profile applications in a PLC
With the AIF control byte it is possible to read the codes C23XX saved in the 9300 Servo PLC,
Drive PLC and ECS into the communication module.
Execute command
How to accept the values in the communication module:
ƒ Write the table value of the required command into the AIF control byte.
ƒ Change the status of the MSB of the AIF control byte. The command is executed.
