background image

Codes

Communication−relevant Lenze codes

14

l

121

EDSMF2178IB EN 3.0

C1822:
AIF−IN all words

Code

Subcode

Index

Possible settings

Data type

Lenze

Selection

C1822

/1:
...
/12:

22753 =
0x58E1

g

U16

All AIF−IN words as 16−bit values

C1823:
AIF−OUT all words

Code

Subcode

Index

Possible settings

Data type

Lenze

Selection

C1823

/1:
...
/12:

22752 =
0x58E0

g

U16

All AIF−OUT words as 16−bit values

C1824:
AIF−IN all double words

Code

Subcode

Index

Possible settings

Data type

Lenze

Selection

C1824

/1:
...
/11:

22751 =
0x58DF

g

U32

All AIF−IN double words as 32−bit values, with an offset of 16 bits each.

(

66)

C1825:
AIF−OUT all double words

Code

Subcode

Index

Possible settings

Data type

Lenze

Selection

C1825

/1:
...
/11:

22750 =
0x58DE

g

U32

All AIF−OUT double words as 32−bit values, with an offset of 16 bits each.

(

66)
