Process data transfer

Cyclic process data objects

Process data signals of Lenze controllers

9

l

61

EDSMF2178IB EN 3.0

9.3.1.3

Process data signals for 9300 Servo PLC, Drive PLC, ECSxA

,

For more information ...

please see the chapter "System blocks, AIF1_IO_AutomationInterface" in the
Manuals and Operating Instructions for the 9300 Servo PLC, Drive PLC and
ECSxA axis module.

)

Note!

Only 9300 Servo PLC & ECSxA:
Perform the following linkings in the PLC program of the drive controller:

ƒ

AIF1_wDctrlCtrl

W

DCTRL_wAIF1Ctrl

ƒ

DCTRL_wStat

W

AIF1_wDctrlStat
