Codes
Communication−relevant Lenze codes
14
l
135 EDSMF2178IB EN 3.0
C1867/C2367:
Sync Rx identifier
Code Subcode Index Possible settings Data type
Lenze Selection
C1867 − 22708 =
0x58B4 128 0 [1] 2047 FIX32
C2367 − 22208 =
0x56C0
This code contains the identifier with which the sync telegram is received.
Relation to CANopen
The object I−1005 (COB−ID SYNC message) has a direct influence on this code. Newly
written values in the object are also transferred to code C1867/C2367.
C1868/C2368:
Sync Tx identifier
Code Subcode Index Possible settings Data type
Lenze Selection
C1868 − 22707 =
0x58B3 128 0 [1] 2047 FIX32
C2368 − 22207 =
0x56BF
This code contains the identifier with which the sync telegram is sent.
Relation to CANopen
The object I−1005 (COB−ID SYNC message) has a direct influence on this code. Newly
written values in the object are also transferred to code C1868/C2368.
