Codes
Communication−relevant Lenze codes
l
133
EDSMF2178IB EN 3.0
C1860:
Display of the current DIP switch position
Code
Subcode
Index
Possible settings
Data type
Lenze
Selection
C1860
−
22715 =
0x58BB
g
U16
By displaying the current DIP switch position it is possible to find out if the switch position
for node address and baud rate has changed since the last initialisation.
DIP switch valencies
Switch
−
1
2
3
4
5
6
7
8
9
10
Value
−
512
256
128
64
32
16
8
4
2
1
Bit
15 ... 10
9
8
7
6
5
4
3
2
1
0
Example for DIP switch position
ƒ
Switches 3, 5, 6, 7 = ON (address 23)
ƒ
Switches 8, 9, 10 = OFF (baud rate 500 kbit/s)
The sum of the corresponding valencies "0xB8" (184) is displayed when code
C1859/C2359 is read.
C1861:
Display of the active CAN node address
Code
Subcode
Index
Possible settings
Data type
Lenze
Selection
C1861
−
22714 =
0x58BA
g
FIX32
Display of the CAN node address active on the CAN bus.
C1862:
Display of the active baud rate
Code
Subcode
Index
Possible settings
Data type
Lenze
Selection
C1862
−
22713 =
0x58B9
g
0:
1:
2:
3:
4:
5:
6:
500 kbps
250 kbps
125 kbps
50 kbps
1000 kbps
20 kbps
10 kbit/s
FIX32
Display of the baud rate active on the CAN bus.
