Commissioning
Setting node address and baud rate
6
l
35 EDSMF2178IB EN 3.0
Baud rate setting
1 2 3 4 5 6 7 8 910
OPEN
ON
OFF
Bd Address
Fig. 6−2 Baud rate setting
ƒ The baud rate must be the same for all CAN nodes.
ƒ The following baud rates can be set:
Baud rate [kbps] Switch
8 9 10
10 ON ON OFF
20 ON OFF ON
50 OFF ON ON
125 OFF ON OFF
250 OFF OFF ON
500 OFF OFF OFF
1000 ON OFF OFF
)
Note!
Switch off the voltage supply of the communication module, and then switch
it on again to activate the changed settings.
