Installation
Electrical installation
Bus cable length
l
29
EDSMF2178IB EN 3.0
5.2.5.3
Checking the use of repeaters
Compare the values derived from Tab. 5−1 Total cable length (
¶ 27) and Tab. 5−2 Segment
cable length (
¶ 28).
ƒ
If the sum of the segment cable lengths is smaller than the total cable length to be
implemented, either repeaters must be used or the cable cross−section must be
increased.
ƒ
If the use of repeaters reduces the max. possible total cable length so much that it is
smaller than the total cable length to be implemented, then the cable cross−section
must be increased or less repeaters must be used or the baud rate must be
decreased.
ƒ
The use of a further repeater is recommended as ...
– service interface
Advantage: Trouble−free connection during bus operation is possible.
– calibration interface
Advantage: The calibration/programming unit remains electrically isolated.
Example
Given
Total cable length to be implemented
450 m
Number of nodes
32
Cable cross−section
0.50 mm
2
(AWG 20)
Baud rate
125 kbps
Repeater used
Lenze repeater EMF2176IB
Reduction of the max. total cable length per
repeater (EMF2176IB)
30 m
Results
Max. total cable length
630 m
(see Tab. 5−1 Total cable length (
^ 27))
Max. segment cable length
360 m
(see Tab. 5−2 Segment cable length (
^ 28))
Comparison
The max. segment cable length is smaller than the total cable
length to be implemented.
Conclusion
A repeater must be installed at the determined max. segment
cable length of 360 m.
Results with 1 repeater
Max. total cable length
600 m
(Reduction of the total cable length (
Max. segment cable length
720 m
Comparison
Both the possible total cable length and the segment cable lengths
are larger than the total cable length to be implemented.
Conclusion
1 repeater is sufficient to implement the total cable length of 450
m.
