Lenze EMF2178IB User Manual
Page 41

Replacing the EMF2172IB communication module (CAN)
l
41
EDSMF2178IB EN 3.0
Activate the 2. SDO channel
Depending on the standard device used, set code C1865/1 or C2365/1 to activate the
2. SDO channel.
Settings via the GDC/XT keypad for these standard devices:
EVS 93xx−ES
EVS 93xx−EP
EVS 93xx−EK
EVS 93xx−ER
EVF 93xx−EV
E82EVxxx
EVS 93xx−EI
EVS 93xx−ET
EPL−10200
ECSxS/P/M/A
1. Plug the EMF2178IB communication module onto
the standard device.
Use the GDC or XT keypad to set standard device code
C2365/1 = 1 and save it with mains failure protection.
After mains connection of one of the standard devices
specified above, or after plugging on the EMF2178IB
communication module, the contents of C2365 are
written to the communication module.
2. Use the GDC to set code C1865/1 = 1.
The setting is saved with mains failure protection
directly in the communication module.
When using the standard devices specified above,
the setting can also be carried out beforehand.
