Codes
Communication−relevant Lenze codes
14
l
119 EDSMF2178IB EN 3.0
14.2 Communication−relevant Lenze codes
The configuration of the entire system where the individual controller often only
represents one of many components in general is defined or altered during the
commissioning phase or during service.
For configuring the Lenze controllers, parameters are provided which are stored as
so−called "codes" in a numerically ascending order in the memory of the controller.
All codes can be accessed via the CAN bus.
The following codes are available for communication via the CAN bus:
ƒ Codes C1810 ... C1825 and C1860 ... C1862:
– For all devices.
– These codes are stored in the EMF2178IB communication module.
ƒ Codes C1827 ... C1882
– For 8200 vector and 93XX controllers.
– These codes are stored in the EMF2178IB communication module.
ƒ Codes C2327 ... C2382:
– For 9300 Servo PLC, Drive PLC and ECS.
– These codes are stored in the controller.
Communication with the drive requires that the system identifies the drive as node. The
identification takes place in the initialisation phase of the communication module.
How to read the tables
Column Meaning
Code (Lenze) code
Subcode Subcode
Index Information on the addressing of the code
Lenze Lenze setting of code
g
Display code
Configuration of this code is not possible.
Selection Minimum value [minimum increment/unit] maximum value
For a display code, the displayed values are specified.
Data type FIX32 32−bit value with sign; decimal with 4 decimal positions
S8 8−bit value, with sign
S16 16−bit value, with sign
S32 32−bit value, with sign
U8 8−bit value, without sign
U16 16−bit value, without sign
U32 32−bit value, without sign
VS Visible string, character string with defined length
