Lenze EMF2178IB - Manual (Page 116)

Codes
Overview
14
l
116 EDSMF2178IB EN 3.0
Info Designation Index
(dec = hex) Subcode Code
C1813 1 ... 4 22762 =
0x58EA Software creation date in subcodes ^ 120
C1822 1 ... 12 22753 =
0x58E1 AIF input words ^ 121
C1823 1 ... 12 22752 =
0x58E0 AIF output words ^ 121
C1824 1 ... 11 22751 =
0x58DF AIF input double words
^ 121
C1825 1 ... 11 22750 =
0x58DE AIF output double words ^ 121
C1827 − 22748 =
0x58DC Guard time ^ 122
C1828 − 22747 =
0x58DB Life time factor ^ 122
C1850 − 22725 =
0x58C5 CAN node address ^ 123
C1851 − 22724 =
0x58C4 Baud rate ^ 124
C1852 − 22723 =
0x58C3 Master / slave operation ^ 125
C1853 1...3 22722 =
0x58C2 Addressing CAN−INx/CAN−OUTx ^ 126
C1854 1 ... 6 22721 =
0x58C1 Individual addressing CAN−INx / CAN−OUTx ^ 129
C1855 1 ... 6 22720 =
0x58C0 Display of resulting identifiers CAN−IN / CAN−OUT ^ 129
C1856 1 ... 5 22719 =
0x58BF Boot up and cycle times ^ 130
C1857 1 ... 6 22718 =
0x58BE Monitoring times ^ 131
C1859 − 22716 =
0x58BC Display of the DIP switch position during initialisation ^ 132
C1860 − 22715 =
0x58BB Display of the current DIP switch position ^ 133
C1861 − 22714 =
0x58BA Display of the active CAN node address ^ 133
C1862 − 22713 =
0x58B9 Display of the active baud rate ^ 133
C1864 − 22711 =
0x58B7 PDO transmission with status change to "Operational" ^ 134
C1865 1 ... 4 22710 =
0x58B6 Validity of SDO2 and PDOs ^ 134
C1867 − 22708 =
0x58B4 Sync Rx identifier ^ 135
C1868 − 22707 =
0x58B3 Sync Tx identifier ^ 135
C1869 − 22706 =
0x58B2 Consumer heartbeat ID ^ 136
C1870 1 ... 2 22705 =
0x58B1 Heartbeat time (consumer, producer) ^ 136
C1871 − 22704 =
0x58B0 Emergency ID ^ 137
C1872 − 22703 =
0x58AF Emergency inhibit time ^ 137
