KPM I Monitor Operation
STEP 6 When all the seed tubes w/sensors for the current
section are installed, check to be sure the monitor
displays solid numbers for the number of sensors
connected.
®
STEP 7 If this condition is satisfied, press and hold the OK
key to save the setup for the current section. The
SAVE? icon shows followed by continuous short
beeps indicating monitor is preparing to save. The
installer has 5 seconds to decide to save the current
configuration. During this time the short beeps
will sound. To complete the save, hold the OK key
pressed until the word “DONE” shows on the screen
followed by a long beep and the SAVE? icon turns off.
When the OK key is released the monitor continues
with the second section installation.
®
®
NOTE: Individual seed tubes may be unplugged for special
situations. An alarm sounds which can be silenced by
touching the OK key. The monitor recognizes each seed tube
when reconnected.
®
STEP 8 Follow STEPS 5 through 7 to install the second
section. If no seed tubes are installed on the
second section, press and hold the OK key until
“DONE” shows on the screen followed by a long
beep and the SAVE? icon turns off.
®
See “KPM I/KPM II Stack-
Mode Electronic Seed Monitor
Troubleshooting” in the
Troubleshooting section of this
manual.
