Model 3200 M0241-01
6/11 6-11
KPM II Monitor Operation
PROGRAMMING - UNITS (METRIC OR ENGLISH)
STEP 1 Press and hold SETUP key to enter programming
mode. The monitor emits several short beeps,
followed by a long beep. On the lower LCD, the
SETUP icon turns on and the arrow head icon will
flash, indicating that the user can select an item to
program.
NOTE: The monitor must be in a programmable function
(row spacing, units, speed, volume or area) to enter setup.
The monitor will not enter setup in seed population or seed
spacing.
STEP 2 Press UP or DOWN arrow keys to move the flashing
arrow to UNITS. As the arrow icon moves, the lower
LCD will display the current setting of the item
selected.
STEP 3 Press the OK key and the flashing arrow becomes
solid and audible alarm sounds.
NOTE: Lower LCD alternately displays Metric or English
icons, indicating Metric or English mode.
•Use UP or DOWN arrow keys to change the setting.
STEP 4 Press and release the OK key to exit without saving.
The monitor restores lower LCD to show item setting,
and the arrow icon flashes, allowing user to select
another item to program.
Press and hold OK key to exit and save. The monitor
emits several short beeps and SAVE? icon is turned
on. After a short time a long beep is heard, and the
lower LCD displays “DONE”. Release the OK key. If
the OK key is released BEFORE “DONE” displays,
changes WILL NOT BE SAVED. “DONE” MUST be
displayed for the save to have occurred.
NOTE: Programming mode may be exited at any time, by
pressing the SETUP key. Pressing this key returns the
monitor to its normal operation. All items changed and
saved come into effect immediately. Any items changed, but
not saved revert to original programmed value.
PROGRAMMING - ROW SPACING
STEP 1 Application mode (rear/front, left/right or four sections)
must be active before entering programming mode. If
monitor is programmed in a rear/front configuration,
both sections are active (alternating every 5 seconds
if the SMM console is not used). You can then set row
spacing to Interplant System row spacing.
EXAMPLE: On a 12 Row 30" with Interplant Package
set row spacing to 15.0 with front active.
When monitor is in normal field operation mode,
disabling front section automatically changes row
spacing to 30".
STEP 2 To enter programming mode, press and hold SETUP
key. Monitor will emit several short beeps, followed
by a long beep. On lower LCD, the SETUP icon turns
on and arrow head icon will flash, indicating that user
can select an item to program.
NOTE: Monitor must be in a programmable function (row
spacing, units, speed, volume or area) to enter setup. Monitor
will not enter setup in seed population or seed spacing.
STEP 3 Press UP or DOWN arrow keys to move flashing
arrow to ROW SPACING. As arrow icon moves, lower
LCD displays current setting of selected item.
STEP 4 Press OK key and flashing arrow becomes solid and
the audible alarm sounds.
NOTE: Lower LCD displays current row spacing (in inches or
centimeters) and ROW SPACING icon is turned on.
•Least significant digit of displayed value blinks.
•This value can be changed by pressing UP or
DOWN arrow keys.
•Once digit is correct, press MODE SELECT key and
blinking digit moves to next significant digit, where
process can be repeated.
NOTE: Monitor limits entry of row spacing from 10.0 inches
(25.4 cm) to 99.9 inches (253.7 cm). If monitor is configured to
a rear/front configuration, limits change to a minimum of 5.0
inches (12.7 cm) and a maximum of 49.9 inches (126.8 cm).
STEP 5 To exit without saving, press and release OK key.
Monitor restores lower LCD to show setting of the
item and arrow icon will flash, allowing user to select
another item to program.
To exit and save, press and hold OK key. Monitor will
emit several short beeps and SAVE? icon is turned
on. After a short time a long beep is heard, and lower
LCD will display the word “DONE”. Release OK key.
If OK key is released BEFORE the word “DONE” is
displayed, changes WILL NOT BE SAVED. The word
“DONE” MUST be displayed in order for the save to
have occurred.
To exit setup mode, press SETUP key.
NOTE: Programming mode may be exited at any time, by
pressing SETUP key. Pressing this key will return monitor to
its normal operation. All items changed and saved will come
into effect immediately. Any items changed, but not saved
revert to original programmed value.
