KPM III Monitor Operation
CHANGING VOLUME, CONTRAST, AND bACKLIGHTING
WITH AV KEy
Alarm, volume, LCD screen contrast, and backlighting may be
adjusted at any time, regardless of what is displayed on screen.
STEP 1
Press AV key. Contrast adjustment dialog box
appears in center of display.
STEP 2
Use arrow keys or turn rotary encoder knob to adjust
contrast. Adjustment will be visible on the screen.
STEP 3
To adjust speaker or backlight, go to STEP 4. If
finished press Enter key to save and exit.
STEP 4
Press AV button a second time. The Backlight
adjustment dialog box will appear in center of the
display.
STEP 5
Use arrow keys or turn knob to adjust backlighting.
The effect of the adjustment will be visible on display.
STEP 6
To adjust speaker go to STEP 7. If finished press
Enter key to save and exit.
STEP 7
Press AV button a third time. Speaker adjustment
dialog box will appear in center of display.
STEP 8
Use arrow keys or turn knob to adjust speaker
volume. Volume of sound emitted from speaker
changes as adjustment is made.
STEP 9
Press knob, Enter key or press AV button a fourth
time to save volume, contrast, and backlight settings.
Status
RowPop
Area
Other
Spacing
MPH
Avg
Pop
0
0.0
1 2 3 4 5 6 7 8 9 10 11 12
1 2 3 4 5 6 7 8 9 10 11 12
120
110
100
90
80
70
60
%
120
110
100
90
80
70
60
%
Contrast
Status
RowPop
Area
Other
Spacing
MPH
Avg
Pop
0
0.0
1 2 3 4 5 6 7 8 9 10 11 12
1 2 3 4 5 6 7 8 9 10 11 12
120
110
100
90
80
70
60
%
120
110
100
90
80
70
60
%
Backlight
Status
RowPop
Area
Other
Spacing
MPH
Avg
Pop
0
0.0
1 2 3 4 5 6 7 8 9 10 11 12
1 2 3 4 5 6 7 8 9 10 11 12
120
110
100
90
80
70
60
%
120
110
100
90
80
70
60
%
Speaker
CONFIGURING PLANTER MONITOR
When the KPM III is powered on for the first time it will go directly
into the Planter Configuration screen (STEP 4).
NOTE: Planter Configuration screen displays planter rows
as programmed into KPM III software. The above screen
shows 12 front (Interplant) rows and 12 rear rows. If the KPM
III were programmed for 8 front (Interplant) rows and 8 rear
rows the screen would display 8 front and 8 rear rows.
STEP 1
Press the F6 key until Mode Selection screen
appears.
NOTE: There are 5 choices on the Mode Selection screen;
1.
Setup mode
2.
Acre count mode
3.
Disable Interplant (Enabled now) mode
4.
Data logging mode
5.
Test mode
STEP 2
Select ‘‘1. Setup Mode’’ by turning the rotary encoder
knob or using the arrow keys. Press the knob or
Enter key to display the highlighted item.
NOTE: There are 10 choices on the Setup Mode screen;
1.
General Settings
2.
Seed Meter Settings
3.
Row Unit Alarm Levels
4.
Setup Data Logging
5.
Configure Planter Monitor
6.
Add New Muxbus Sensors
7.
Add Single Interplant
®
Row
8.
Select Speed Sensor
9.
Sensor Setup
10.
Calibrate Speed Sensor
RowPop
Spacing
Area
Other
Accuracy
MPH
Avg
Pop
0
0.0
1 2 3 4 5 6 7 8 9 10 11 12
1 2 3 4 5 6 7 8 9 10 11 12
120
110
100
90
80
70
60
%
120
110
100
90
80
70
60
%
Status
Plant
About
Kinze Planter Monitor III
Lifetime Area:
Please select the operating mode for the
planter monitor or the action to perform.
Effective row spacing: 15.0
0.00
1. Setup Mode
2. Acre Count Mode
3. Disable Interplant (Enabled now)
4. Data logging disabled
5. Test Mode
