91
4 Configuration parameters
Configuration ➔ Texts
Configuration ➔ Interfaces
from text No.
(in PCA 3000) Configuration
➔ El. signature
➔ Text list signif.
➔ in PCA 3000
➔ from text No.
1 — 146 First text in the internal text
list.
to text No.
(in PCA 3000) Configuration
➔ El. signature
➔ Text list signif.
➔ in PCA 3000
➔ to text No.
1 to 2 to 146 Last text in the internal text
list.
Parameter Value/selection Description
Parameter Value/selection Description
Texts Configuration
➔ Texts Text 1 — 146
v Chapter 3.8 “Text entry”
Parameter Value/selection Description
20 (RS232/RS4xx) Configuration
➔ Interfaces
➔ 20 (RS232/RS4xx)
Setting the parameters for
the serial interface
Protocol
(20 (RS232/RS4xx)) Configuration
➔ Interfaces
➔ 20 (RS232/RS4xx)
➔ Protocol
MODBUS,
JBUS
Baud rate
(20 (RS232/RS4xx)) Configuration
➔ Interfaces
➔ 20 (RS232/RS4xx)
➔ Baud rate
9600 baud,
19200 baud,
38400 baud If possible, the fastest
transfer rate should be
selected here. The next
smaller rate should only be
selected if problems arise.
Data format
(20 (RS232/RS4xx)) Configuration
➔ Interfaces
➔ 20 (RS232/RS4xx)
➔ Data format
8-1-none,
8-1-odd,
8-1-even,
8-2-none
Device address
(20 (RS232/RS4xx)) Configuration
➔ Interfaces
➔ 20 (RS232/RS4xx)
➔ Device address
1 — 254
Min. response time
(20 (RS232/RS4xx)) Configuration
➔ Interfaces
➔ 20 (RS232/RS4xx)
➔ Min. response
time
0 — 500msec
21 (Profibus-DP) Configuration
➔ Interfaces
➔ 21 (Profibus-DP)
Setting the parameters for
the Profibus-DP interface.
