JUMO 706560 LOGOSCREEN es Operating Manual - Manual (Page 84)

4 Configuration parameters
84
Measurement
representation
Report
(group 1 — 6) Configuration
➔ Group config.
➔ Group 1 — 6
➔ Measurement
representation
➔ Report
Off,
On
Measurement
representation
Batch
(group 1 — 6) Configuration
➔ Group config.
➔ Group 1 — 6
➔ Measurement
representation
➔ Batch
Off,
On
Store status
Normal operation
(group 1 — 6) Configuration
➔ Group config.
➔ Group 1 — 6
➔ Normal operation
➔ Store
status
Off,
On
Stored value
Normal operation
(group 1 — 6) Configuration
➔ Group config.
➔ Group 1 — 6
➔ Normal operation
➔ Stored value
Average val.,
Instant val.,,
Minimum,
Maximum
v Chapter 2.7 “Operating
modes”
Chapter 2.8 “Storing
data”
Storage cycle
Normal operation
(group 1 — 6) Configuration
➔ Group config.
➔ Group 1 — 6
➔ Normal operation
➔ Storage
cycle
0 — 60 — 32767s
v Chapter 2.7 “Operating
modes”
Chapter 2.8 “Storing
data”
Setting 0s =
Storage cycle 125ms
Control signal
Event operation
(group 1 — 6) Configuration
➔ Group config.
➔ Group 1 — 6
➔ Event operation
➔ Control signal
Off,
LogInp.1 — 7,
Alarm Gr.1 — 6,
Combination alarm,
Logged in,
Error,
Modbus flag
Ext. Inp. 1 — 6,
CF inserted
CF stolen
Int. mem. al./CF,
Int. mem. al./ser,
Mem. al./CF card When the configured signal
is active, the device
switches to event
operation.
Stored value
Event operation
(group 1 — 6) Configuration
➔ Group config.
➔ Group 1 — 6
➔ Event operation
➔ Stored value
Average val.,
Instant val.,,
Minimum,
Maximum
v Chapter 2.7 “Operating
modes”
Chapter 2.8 “Storing
data”
Storage cycle
Event operation
(group 1 — 6) Configuration
➔ Group config.
➔ Group 1 — 6
➔ Event operation
➔ Storage cycle
0 — 5 — 32767s v Chapter 2.7 “Operating
modes”
Chapter 2.8 “Storing
data”
Parameter Value/selection Description
