JUMO 706560 LOGOSCREEN es Operating Manual - Manual (Page 111)

111
5 Setup software
5.8.2 Data transfer
Make
connection This function establishes a connection to a device. A connection to a device is
a precondition for transferring a setup to or from a device via an interface
(serial or Ethernet).
Break
connection Breaks an existing connection. A connection to a device must be broken
before a new connection can be established to another device.
Data transfer to
device Transmits a setup to a device.
Data transfer
from device Reads in a setup from a device. If there is no connection, the software will
automatically attempt to access the default device.
Data export to
CF card The setup will be saved on a CompactFlash card. The CompactFlash card can
be read by the device.
Data import
from CF card Reads a setup from a CompactFlash card, and displays it in the working area.
5.8.3 Extras
Enable program
options If no valid serial number was entered during the installation of a program, then
it will only run in demo mode, and some functions, e.g. “save”, will be blocked.
This function can be used to register a program at a later date and so change
it from a demo version into a full version.
Enable extra
codes This function is intended for later extensions within the paperless recorder.
After starting up the function, a code number must be read out from the
device, using the button, and then passed on to the
manufacturer. The manufacturer will then produce a “release” number. The
button is used to transmit this release number to the device,
which then enables the new device function.
H
All the functions in the Extras menu which require access to a
device must have a connection to the device.
If there is no connection, the setup software will try to access the
default device from the device list. If no default device has been
defined, then the device list will appear on the screen and the user
must set up a connection by hand.
