4 Configuration parameters
Decimal place
(internal analog
inputs and counters)
Configuration
➔ Analog inputs
➔ Analog input 1 — 12
Counter 1 — 2
➔ Addit’l parameters
➔ Decimal place
Automatic,
X.XXXX,
XX.XXX,
XXX.XX,
XXXX.X
(for analog inputs),
XXXXX. (for counters)
Automatic: representation
with maximum resolution
Integrator
time base
(internal analog
inputs)
Configuration
➔ Analog inputs
➔ Analog input 1 — 12
➔ Addit’l parameters
➔ Integr.
time base
Off,
Second,
Minute,
Hour,
Day
Time base for the
integrator. If the time base
is switched off, the
integrator indication is
suppressed in the report.
v Chapter 2.6 “Integrator”
Integrator unit
(internal analog
inputs)
Configuration
➔ Analog inputs
➔ Analog input 1 — 12
➔ Addit’l parameters
➔ Integr. unit
5 characters
Sensor
(external
analog inputs and
counters)
Configuration
➔ Analog inputs
➔ External input
1 — 36
External counter 1—2
➔ Sensor
Off,
Ext. input,
Ext. counter
Scaling start
(external
analog inputs and
counters)
Configuration
➔ Analog inputs
➔ External input
1 — 36
External counter 1—2
➔ Scaling start
-99999 to 0 to +99999
Scaling end
(external
analog inputs and
counters)
Configuration
➔ Analog inputs
➔ External input
1 — 36
External counter 1—2
➔ Scaling end
-99999 to +100 to +99999
(for analog inputs)
-99999 to +10000 to
+99999
(for counters)
Channel name
(external
analog inputs and
counters)
Configuration
➔ Analog inputs
➔ External input
1 — 36
External counter 1—2
➔ Addit’l parameters
➔ Channel name
7 characters
Short designation. It is
shown in all diagram
representations.
Channel
description
(external
analog inputs and
counters)
Configuration
➔ Analog inputs
➔ External input
1 — 36
External counter 1—2
➔ Addit’l parameters
➔ Channel
description
2 x 20 characters
Detailed description. It is
additionally shown in the
two numerical displays.
Parameter
Value/selection
Description
