4 Configuration parameters
86
Configuration ➔ Control functions
Control signal
Outputs Configuration
➔ Outputs
➔ Relay K2 — K5,
Open-collector
➔ Control signal
Off,
LogInp.1 — 7,
Alarm Gr.1 — 5,
Combination alarm,
Logged in,
Error,
Modbus flag
Ext. Inp. 1 — 6,
CF inserted
CF stolen
Int. mem. al./CF,
Int. mem. al./ser,
Mem. al./CF card The configured signal is
output to the relay.
Parameter Value/selection Description
Parameter Value/selection Description
Control signal
(counters) Configuration
➔ Control functions
➔ Counters
➔ Counter 1 — 2
➔ Control signal
Off,
LogInp.1 — 7,
Alarm Gr.1 — 6,
Combination alarm,
Logged in,
Error,
Modbus flag
Ext. Inp. 1 — 6,
CF inserted
CF stolen
Int. mem. al./CF,
Int. mem. al./ser,
Mem. al./CF card The counter is incremented
or decremented when the
control signal becomes
active.
v Chapter 2.5 “Counters”
Start value
(counters) Configuration
➔ Control functions
➔ Counters
➔ Counter 1 — 2/
Ext. counter 1 — 2
➔ Start value
-9999 to 0 to +9999 Sets the counter to the
specified value.
v Chapter 2.5 “Counters”
Counting direction
(counters) Configuration
➔ Control functions
➔ Counters
➔ Counter 1 — 2/
Ext. counter 1 — 2
➔ Counting
direction
Up,
Down
v Chapter 2.5 “Counters”
Text
(counters) Configuration
➔ Control functions
➔ Counters
➔ Counter 1 — 2/
Ext. counter 1 — 2
➔ Text
Standard text,
Text 1 — 146,
No text v Chapter 2.5 “Counters”
Chapter 3.5 “Event list /
AT”
v Configuration ➔ Texts,
page 91
