4 Configuration parameters
Configuration ➔ Outputs
Start time
Timed operation
(group 1 — 6) Configuration
➔ Group config.
➔ Group 1 — 6
➔ Timed operation
➔ Start time
any time Off when
Start time =
End time
End time
Timed operation
(group 1 — 6) Configuration
➔ Group config.
➔ Group 1 — 6
➔ Timed operation
➔ End time
any time
Stored value
Timed operation
(group 1 — 6) Configuration
➔ Group config.
➔ Group 1 — 6
➔ Timed operation
➔ Stored value
Average val.,
Instant val.,,
Minimum,
Maximum
v Chapter 2.7 “Operating
modes”
Chapter 2.8 “Storing
data”
Storage cycle
Timed operation
(group 1 — 6) Configuration
➔ Group config.
➔ Group 1 — 6
➔ Timed operation
➔ Storage cycle
0 — 5 — 32767s
v Chapter 2.7 “Operating
modes”
Chapter 2.8 “Storing
data”
Parameter Value/selection Description
Parameter Value/selection Description
Action
Outputs Configuration
➔ Outputs
➔ Relay K1
➔ Action
Off,
make (n.o.),
break (n.c.)
Control signal
Outputs Configuration
➔ Outputs
➔ Relay K1
➔ Control signal
Off,
LogInp.1 — 7,
Alarm Gr.1 — 6,
Combination alarm,
Logged in,
Error,
Modbus flag
Ext. Inp. 1 — 6,
CF inserted
CF stolen
Int. mem. al./CF,
Int. mem. al./ser,
Mem. al./CF card The configured signal is
output to the relay.
Action
Outputs Configuration
➔ Outputs
➔ Relay K2 — K5,
Open-collector
➔ Action
Off,
make (n.o.),
break (n.c.)
