9.8. MENU ANALOG – Analog inputs/outputs
REG+EPROG STAND-BY ALARM
XXXXX
MENU
ANALOG

In order to use the analog inputs and outputs, the recirculating cooler
must be equipped with the Analog Interface Modul available as option.
This submenu enables setting of the input and output values for the
programmer input and the temperature recorder outputs of socket
REG+E-PROG.
The >STAND-BY< input and the >ALARM< output are configurable.
F-ALARM
Function at alarm
A-ALARM
Type of alarm
EX-STBY
STAND-BY input
ACTINT [°C]
internal actual
temperature value
(bath temperature)
ACTEXT [°C]
external actual
temperature value
(external sensor)
S-POINT [°C]
active setpoint
temperature
POWER [%]
SETP [°C]
Setpoint
FLOWRAT [L/M]
ACTVAR [%]
Actuating variable
ANALOG: Press enter
to switch to menu level 2
>F-ALARM< (STANDBY / ALARM / AL-STBY)
>A-ALARM< ( NORMAL / INVERS )
>EX-STBY < (INACTIV / ACTIV)
>CHANNEL < (1 / 2 / 3)
>CH1 < (ACTINT/ ACTEXT/ POWER/ S-POINT)
>CH1 0V< (-99.90 )
>CH1 10V< (300.00 )
or
>CH2 < (POWER/ S-POINT/ ACTINT/ ACTEXT)
>CH2 0V< (0.00 )
>CH2 10V< (100.00 )
or
>CH3 < (S-POINT/ ACTINT/ ACTEXT/ POWER)
>CH3 < (0-20MA / 4-20MA)
>CH3 0MA< (-99.90 )
>CH3 20MA< (300.00 )
>EPROG < (VOLTAGE (U) /
CURRENT
(I))
> EPROG U< (SETP / FLOWRAT / ACTVAR)
> UW °C< (-99.90 )
> OW °C< (300.00 )
