JULABO SC 10000w Professional Series Recirculating Coolers - Manual (Page 12)

Operator responsibility – Safety instructions
12
Professional Series
SC 10000w
Working temperature ranges:
Standard unit °C +5 ... +35
Option Low Temp °C -20 ... +35
Option Low /HighTemp I °C -20 ... +80
Option Low /HighTemp II °C -20 ... +130
Temperature stability °C 0.1
A
bsolute Temperature Calibration INT/EXT ±3 / ±9
Heater wattage (at 230 V) Option H5 kW 5.0
Heater wattage (at 230 V) Option H12 kW 12.0
Cooling capacity °C +20 0 -10
Medium ethanol kW 10 5.0 2.5
Refrigerant R404A
Pump capacity P3 (Standard) / P4 * (Option)
see table 1 page 13
Flow rate P3 / P4 lpm at 0 bar 33 / 43
Pressure max. P3 / P4 bar at 0 liters 3.5 / 4.4
Overall dimensions (WxDxH) cm 59x67/112
Filling volume liters 43 ... 60
Weight kg 155
Ambient temperature °C 5 ... 40
Mains power connection V/ Hz
365-440 V/3PNPE/50 Hz
400/50/3 phases
Current consumption without heater A 11/ phase
Current consumption (at 400 V) 5 kW heater A 23/ phase
Current consumption (at 400 V) 12 kW heater A
36/ phase
Mains power connection V/ Hz
197-254 V/3PPE/60 Hz
208-230/60/3 phases
Current consumption without heater A 18/phase
Current consumption (at 230 V) 5 kW heater A 25/ phase
Current consumption (at 230 V) 12 kW heater A 45/ phase
All measurements have been carried out at: rated voltage and frequency ambient temperature: 20 °C
Technical changes without prior notification reserved.
* Pump P4- reduces cooling capacity by 0.3 kW
