JULABO SC 10000w Professional Series Recirculating Coolers - Manual (Page 53)

Recirculating Cooler
53
9.7. MENU ADJUST – ATC Absolute Temperature Calibration
ATC serves to compensate a temperature difference that might occur
between recirculating cooler and a defined measuring point in the bath
tank because of physical properties.
XXXXX
MENU
ADJUST
ADJUST: Press enter
to switch to menu level 2
>ATC SEN <
(INT) or (EXT)
> ATCSTAT < > ATCSTAT <
(ON or OFF) (ON or OFF)
>C ART >C ART
>1- point <-, >2- point <- or >3- point < - calibration
> TTEMP 1< > TTEMP 1<
> CTEMP 1< > CTEMP 1<
> TTEMP 2< > TTEMP 2<
> CTEMP 2< > CTEMP 2<
> TTEMP 3< > TTEMP 3<
> CTEMP 3< > CTEMP 3<
1.
Press the button until the desired submenu is displayed.
2.
Set value /parameter:
Use the cursor keys to move left or right on the display until
the numeral you wish to change blinks.
Use the increase/decrease arrows
to change the selected
numeral (-, 0, 1, 2, 3, ... 9).
or
select the parameter with the keys .
3. Press enter to store the value / parameter
Continue: Press / or
