Temperature System Magnum 91

29

Adjusting Mode:

Press the respective keys in the following order:

1. MENUE

key

1x

2. Cursor

key

up to Submenu "Pump"

3. Enter

key

1x

4. Cursor

key

1x up to "Pump"

5. P-

key

sys open / sys close / fill / drain

6. Enter

key

1x

7. Escape

key

ESC

2x


The DIALOG-DISPLAY (LCD) helps to follow up the individual
settings.

The VFD-Info Display shows the recently chosen operating status
for approx. 3 seconds.

Switch over to > sys open < OPEN SYSTEN

Switch over to > sys close < CLOSED SYSTEM

Switch over to > fill <

FILL SYSTEM

Switch over to >drain<

DRAIN SYSTEM

Notice concerning the filling

The temperature system was emptied last, therefore the menu option >Mode<
now still stands on >drain<. In the configuration of this unit the >Mode< >fill<
means the same as >drain< and therefore does not have to be adjusted.

Explanation of terms:

>Mode: sys close< stands for closed, external system

(Magnum principle page 18)


>Mode: sys open< stands for open external system

(not recommended by JULABO)
